Magnetic Filter

磁性过滤器Magnetic Filter

用于闭式冷却水和PCW系统中铁氧化物、黑色磁泥和细小铁磁颗粒的去除，保护泵阀和换热器。
Removes iron oxides, black magnetic sludge and fine ferromagnetic particles in closed-loop cooling water and PCW systems to protect pumps, valves and heat exchangers.

Designed to remove iron oxides, black magnetic sludge and fine ferromagnetic particles from closed cooling water and PCW systems, protecting pumps, valves and heat exchangers.

黑泥与铁磁颗粒控制 / Magnetic sludge control

闭式冷却水PCW回路换热器保护泵阀保护

设备原理

Working Principle

高强度磁棒或磁芯在水流通道中形成磁场，捕集铁磁性颗粒，定期通过清洗或排污将污染物排出。

High-intensity magnetic rods or cores create a magnetic field in the flow path to capture ferromagnetic particles, which are removed periodically by cleaning or blowdown.

应用场景

Applications

闭式冷却水 / PCW回路 / 换热器保护 / 泵阀保护

Customized for data center water systems, retrofit projects and overseas delivery.

设备特点

Key Features

对闭式系统黑泥捕集效率高
无滤芯耗材，维护量低
阻力小，可全流或旁流安装
适合与定压补水、闭路超滤联用

Key Features

English

High capture efficiency for black sludge in closed loops
No consumable cartridges and low maintenance
Low pressure loss; suitable for full-flow or side-stream installation
Can be combined with pressurization and closed-loop UF

Configuration

可选配置与交付文件

强磁组件
自动排污
旁流安装
压差监测
不锈钢壳体

郅奕可根据项目现场接口、控制系统、数据中心运维标准和海外交付要求，提供P&ID、I/O清单、控制逻辑、操作说明、调试报告和备件建议。

服务模式	设计选型 / 制造集成 / FAT / 现场调试 / 运维支持
控制方式	手动、本地自动、PLC/HMI、Modbus/远程预留
交付形式	模块化撬装，适合国内项目与海外出口包装
适用行业	数据中心、半导体、电子、工业循环水与纯水系统
